PD Fast Charge

Application scheme

PD fast charging (Power Delivery) is a new fast charging technology in the USB connector, which has wake-up, intelligent negotiation, safety settings and real-time monitoring functions during use, which will achieve lower loss, higher efficiency and safer power transmission during the charging process.

PD fast charging technology could connect multiple devices using a single wire, automatically adjust the charging power according to the power identification function of the device, and use scalable communication technology to achieve flexible fast charging. This means that multiple devices are better charged by a single port, enabling driverless and free charging, i.e. multiple devices could be charged without any software or driver support.

Application Details

X-IPM introduces 1KW bidirectional digital control inverter with small size and high power density, Size: 140mm * 100mm * 40mm, Weight: 600g

230V System, AC to DC power 1000W, DC to AC power 1000W

110V System, AC to DC power 600W，DC to AC power 600W

PV Power: 100~200W

The inverter adopts TI 's DSP as the digital power control chip, and the power device adopts MOSFET + X-IPM SiC diode

The charging adopts high-efficient PFC + LLC + synchronous rectification technology.

Inverter adopts high efficiency DC-DC resonance + Inverter output with synchronous generator characteristics.

Charge Efficiency: 94%, Discharging Efficiency: 93%

AC Side Support: 90--160 165--264VAC

DC Side Support: 10V--80VDC

Fanless, Natural Cooling

It supports multiple charging modes such as EV, PV, PD and VAC.

It supports off-line multiple equipment in parallel

Application Parameters

XPC1KGE Character

Parameter

Brand

110V System Charging Power

600W

—

230V System Charging Power

1000W

—

230V System Inverter Power

1000W

—

AC Side Support

90~160VAC 165~264VAC

—

Charging / Discharging Efficiency

94% / 93%

—

Charging Topology

PFC+LLC+SR

—

DC Side Support

10V~80VDC

—

Inverter Main Controlling

DSP

Inverter Topology

DC-DC Resonance

—

PV Power

24V/240W

—

Power Device

MOS + SiC-SBD

X-IPM xSiC

Size

140*100*35 mm

—
