MANUFACTURING
THINKANTECH YANCHENG FACTORY IS AN ADVANCED POWER MODULE PACKAGING FACILITY. WITH MATURE AND ADVANCED PACKAGING PROCESSES, WE PROVIDE EFFICIENT AND RELIABLE PACKAGING SERVICES, OFFERING CUSTOMERS HIGH QUALITY AND PROFESSIONAL MODULE PACKAGING SOLUTIONS.OUR ADVANCED PROCESSES AND EXPERT TECHNOLOGY ALLOW US TO QUICKLY RESPOND TO CUSTOMIZED REQUIREMENT.
2300㎡
Production Area
1000㎡
Class-10,000 Cleanroom
> 80%
Proportion of imported equipment
Automation
High-precision semi-automated
production line
500,000units/year
IGBT module production capacity
150million RMB
Annual output value
ADVANCED POWER SEMICONDUCTOR MODULE PACKAGING FACILITY
Jiangsu THINKANTECH Yancheng factory is FORMITEK’s strategic facility in power module packaging and system integration. It focuses on the research and development of IGBT modules, IPM (Intelligent Power Modules), and SiC hybrid modules. It also provides customized packaging designs and thermal management solutions. In order to build a high quality product line covering automotive grade and industrial grade standards, the factory has introduced multiple sets of high precision, high reliability production and testing equipment.
High precision placement machines with micron-level positioning ensure accurate alignment of chips and substrates, vacuum reflow ovens maintain soldering stability through controlled environments and stepwise temperature control. Aluminum/copper wire bonding machines enable efficient electrical connections. Dedicated testing machines simulate harsh operating conditions to perform comprehensive performance evaluation.
With superior products and technical support, Jiangsu THINKANTECH serves applications such as electric vehicle drive systems, energy storage inverters, and high-end equipment manufacturing, fully committed to advancing the domestic substitution of power modules.








PROCESS FLOW
YANCHENG FACTORY FOCUSES ON MODULE PACKAGING AND TESTING
Yancheng factory focuses on module
packaging and testing
CHIP MOUNTING PROCESS
Our positioning accuracy reaches ±0.015 mm, with multiple nozzles and customizable adaptation for chips of various thicknesses and specifications.
We can precisely align the chip with the electrodes of the DBC (Direct Bonded Copper) substrate, preventing misalignment that could cause poor electrical connections, and providing a stable foundation for subsequent soldering and bonding processes.
ALUMINUM WIRE BONDING
We are capable of bonding aluminum and copper wires with diameters from 50 µm to 600 µm, achieving a positional repeatability of ±0.005 mm, while keeping bond-strength variation strictly within 5%.
Capable of achieving micrometer-level connections between aluminum wires, chips, and substrates, laying the foundation for stable electrical signal transmission in modules. Using a multi-strand parallel aluminum wire bonding design, parasitic inductance is reduced to below 5 nH, effectively minimizing signal interference under high-frequency conditions.
FORMIC-ACID REFLOW SOLDERING
Our power modules have excellent temperature uniformity at ±0.5%, single-solder-joint void rate ≤ 0.5%, and a 15% reduction in thermal resistance of the solder layer.
As a key process for soldering IGBT chips to DBC substrates, formic-acid vacuum reflow soldering achieves flux-free soldering through a dual effect of ‘formic-acid reduction + high-vacuum environment,’ preventing electrical corrosion caused by residues. The solder joint surface cleanliness reaches 99.9%, providing a solid foundation for the long-term current-carrying reliability of the module.
DYNAMIC/STATIC TESTING
Our power modules are equipped with a high precision measurement module, with a voltage testing range of 0 to 3000 V and a current testing range of 0 to 2000 A. The sampling rate reaches up to 20 GSa/s, testing bandwidth covers DC to 1 GHz, and it can simulate high frequency switching conditions from 5 kHz to 2 MHz
As the ‘key quality checkpoint’ before IGBT modules leave the factory, it comprehensively tests both static characteristics (such as breakdown voltage and gate threshold voltage) and dynamic characteristics (such as switching delay time, di/dt, dv/dt). This ensures that only modules meeting precise parameter standards are delivered, preventing underperforming products from entering downstream applications.
KEY PRODUCTS
THINKANTECH SPECIALIZES IN WIDE BANDGAP SEMICONDUCTOR TECHNOLOGIES (GAN/SIC), OUR PRODUCTS APPLICATIONS INCLUDE FAST CHARGING, ENERGY STORAGE SYSTEMS, AUTOMOTIVE ELECTRONICS, AND AI COMPUTING.
DEVELOPMENT PLAN
WE DEVELOP HIGHLY RELIABLE POWER MODULES TO MEET THE DEMANDS OF MARINE ELECTRONICS, STRIVING TO BECOME THE TOP BRAND IN FUTURE MARINE ELECTRONIC EQUIPMENT.
WE CREATE HIGH EFFICIENCY, HIGH POWER DENSITY POWER MODULES TO ADDRESS THE EVOLVING DEMANDS OF THE BATTERY INDUSTRY.
WE DESIGN EFFICIENT POWER MODULES FOR AI COMPUTING AND SMART TERMINALS.
WE INNOVATIVELY TACKLE HIGH EFFICIENCY ENERGY CONVERSION CHALLENGES TO MEET THE NEW DEMANDS OF SMART HOME APPLIANCES.
